Magnesium Anode 15S Plastisol-Coated

Corrpro manufactures a full line of aqueous magnesium anodes using the H-1 alloying standard. The anodes produce an open circuit potential of 1.53 - 1.55 volts, and are cast into circular, rectangular, square, and teardrop shapes. Mounting designs on Corrpro’s aqueous magnesium anodes were created to address a variety of installation possibilities. Anodes typically associated with condenser applications are constructed with a galvanized steel pipe core for mounting on metal studs. Hull-type anodes, on the other hand, are available with cast in galvanized steel mounting straps for weld or bolt-on attachment.

In addition to these options, the aqueous magnesium anodes can be supplied with a plastisol coating. By employing this special barrier, current output and direction can be controlled, which not only improves the anode’s performance, but also extends its life.

This H-1 15S plastisol-coated magnesium anode includes a ¾"" pipe core and a heavy-duty exterior coating to withstand harsh environments while delivering consistent cathodic protection.
